Details
The branch-on-constant-limits block goes to a branching block if a measurement meets the criteria set by this
command.
The type of limit can be:
• Above: The measurement is above the value set by limit B. Limit A must be set, but is ignored when this
type is selected.
• Below: The measurement is below the value set by limit A. Limit B must be set, but is ignored when this
type is selected.
• Inside: The measurement is inside the values set by limits A and B. Limit A must be the low value and
Limit B must be the high value.
• Outside: The measurement is outside the values set by limits A and B. Limit A must be the low value
and Limit B must be the high value.
The measurement block must be a measurement building block that occurs in the trigger model before the
branch-on-constant-limits block. The last measurement from the measurement building block is used.
Example
trigger.model.setblock(5, trigger.BLOCK_BRANCH_LIMIT_CONSTANT, trigger.LIMIT_ABOVE,
.1, 1, 2)
Also see
Constant limits (on page 3-99)
trigger.model.setblock() —
trigger.BLOCK_BRANCH_LIMIT_DYNAMIC
This command defines a trigger model block that goes to a specified block in the trigger model if a measurement
meets user-defined criteria.
Type TSP-Link accessible Affected by Where saved Default value
Function
Yes
Restore configuration
Instrument reset
Power cycle
Configuration script
Not applicable
Usage
trigger.model.setblock(blockNumber, trigger.BLOCK_BRANCH_LIMIT_DYNAMIC, limitType,
branchToBlock)
trigger.model.setblock(blockNumber, trigger.BLOCK_BRANCH_LIMIT_DYNAMIC, limitType,
branchToBlock, measureBlock)
blockNumber
The sequence of the block in the trigger model
limitType
The type of limit, which can be one of the following types:
• trigger.LIMIT_ABOVE
• trigger.LIMIT_BELOW
• trigger.LIMIT_INSIDE
•
trigger.LIMIT_OUTSIDE
branchToBlock
The block number of the trigger model block to execute when
the measurement meets the criteria set in the configuration list
measureBlock
The block number of the measurement block that makes the
measurement to be compared
