6: SCPI command reference Model 2450 Interactive SourceMeter® Instrument
Reference Manual
6-158 2450-901-01 Rev. B/September 2013
:TRIGger:LAN<n>:OUT:IP:ADDRess
This command specifies the address (in dotted-decimal format) of UDP or TCP listeners.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Save settings "0.0.0.0"
Usage
:TRIGger:LAN<n>:OUT:IP:ADDRess <address>
:TRIGger:LAN<n>:OUT:IP:ADDRess?
<n>
The LAN event number (1 to 8)
<address>
A string that represents the LAN address in dotted decimal notation
Details
Sets the IP address for outgoing trigger events.
After you change this setting, you must send the connect command before outgoing messages can be sent.
Example
TRIG:LAN1:OUT:IP:ADDR "192.0.32.10"
Use IP address 192.0.32.10 to connect the
LAN trigger.
Also see
:TRIGger:LAN<n>:OUT:CONNect:STATe (on page 6-157)
:TRIGger:LAN<n>:OUT:LOGic
This command sets the logic on which the trigger event detector and the output trigger generator operate on the
given trigger line.
Type Affected by Where saved Default value
Command and query
Not applicable
Nonvolatile memory
NEG
Usage
:TRIGger:LAN<n>:OUT:LOGic <logicType>
:TRIGger:LAN<n>:OUT:LOGic?
<n>
The LAN event number (1 to 8)
<logicType>
POSitive
NEGative
Example
TRIG:LAN1:OUT:LOG POS
Set the logic to positive.
Also see
None
