Section

8: TSP command reference Model 2450 Interactive SourceMeter® Instrument

Reference Manual

8-80 2450-901-01 Rev. B/September 2013

Example 1

reset()

testData = buffer.make(200)

format.data = format.ASCII

format.asciiprecision = 6

trigger.model.load("SimpleLoop", 6, 0, testData)

trigger.model.initiate()

waitcomplete()

printbuffer(1, testData.n, testData.readings, testData.units,

testData.relativetimestamps)

This assumes that testData is a valid reading buffer in the run-time environment. The use of testData.n

(bufferVar.n) indicates that the instrument should output all readings in the reading buffer. In this example,

testBuffer.n equals 6.

Example of output data:

1.10458e-11, Amp DC, 0.00000e+00, 1.19908e-11, Amp DC, 1.01858e-01, 1.19908e-11, Amp DC,

2.03718e-01, 1.20325e-11, Amp DC, 3.05581e-01, 1.20603e-11, Amp DC, 4.07440e-01, 1.20325e-

11, Amp DC, 5.09299e-01

Example 2

for x = 1, testData.n do

printbuffer(x,x,testData, testData.units, testData.relativetimestamps)

end

Using the same buffer created in Example 1, output readings, units and relative timestamps on a separate line

for each reading.

1.10458e-11, Amp DC, 0.00000e+00

1.19908e-11, Amp DC, 1.01858e-01

1.19908e-11, Amp DC, 2.03718e-01

1.20325e-11, Amp DC, 3.05581e-01

1.20603e-11, Amp DC, 4.07440e-01

1.20325e-11, Amp DC, 5.09299e-01

Also see

bufferVar.n (on page 8-23)

bufferVar.readings (on page 8-24)

format.asciiprecision (on page 8-62)

format.byteorder (on page 8-63)

format.data (on page 8-64)

printnumber() (on page 8-81)
