3.5 Checking the Stand-Alone Operation
REGIUS MODEL 190 Service Manual Ver.1.00 2004.11.01
3.5 Checking the Stand-Alone Operation
Normally, when the REGIUS 190 which is not networked to the
REGIUS Console is started up, a network error 24000 occurs,
and it will not start even the cassette is inserted.
When it is necessary to operate the REGIUS 190 as stand-
alone, follow the procedures described below.
Impor
tant Do not change the setting of DIP SW
other than SW2- 5 on the MCB2. (for the
rest of DIP SW, refer to "5.2 DIP Switch
Setting", p.184)
Important To terminate the dummy SBC2 program,
confirm that the all dips of DIP SW (SW2)
are set to OFF (left).
1.
Remove the left cover. ("2.2.2 Removal of the Left & Right
Covers", p.29)
2.
Loosen 5 fixing screws, and detach the cover for mechani-
cal control box.
3.
Tu rn the DIP SW (SW2-5) on the MCB2 (Mechanical Con-
trol Board) to ON (right).
4.
Press
operation" button of the REGIUS 190.
• Insert the cassette into the insertion slot. The cassette
will be drawn into the device, and series of operations
including ejection of cassette will be initiated.
ON
SW2-5
MCB2
Left side
To Next Page
