145
4.3 Troubleshooting for Image Quality
REGIUS MODEL 190 Service Manual Ver.1.00 2004.11.01
4.3.12 Case 11: The left and right of the image are disconnected.
• If problems from cases 10 and 11 above repeats after resolution, inform to the manufacturer.
4.3.13 Case 12: Irregularity correction has not been carried out.
• Confirm whether images are being obtained without correction.
• Confirm that the ADB2's high-voltage switch is turned ON.
4.3.14 Case 13: The irregularity correction data is excessive (i.e., 300 steps or more
from MAX to MIN)
Phenomena Cause/Remedy
1 The X-ray exposure restriction is not suit-
able.
Check the exposure field.
2 The sideways-direction start point is not cor-
rect.
Check the sideways-direction start point and modify if neces-
sary.
Phenomena Cause/Remedy
1 The image data for creation of irregularity
correction is bad.
Recreate the irregularity correction using a plate with no sur-
face damage or contamination.
2 If the problem persists after performing the
above.
• Replace the CF card.
• Replace the SCB2. "2.7.3 Replacement of SCB2
(System Control Board), p.84"
Phenomena Cause/Remedy
1 Exposure conditions for the irregularity correc-
tion are not suitable.
Repeat with appropriate exposure condition.
2 Plates or the optical unit's beam collector sec-
tion is soiled.
Clean the soil.
3 Foreign objects are exposed in the correction
image.
Repeat the exposure avoiding any object to be included
in the imaging field.
4 Polygon correction is made excessively. (300
steps or more)
When this remains large even after irregularity correction
is repeated, replace the optical unit. "2.6.2 Replacement
of Optical Unit, p.76"
To Next Page
