1.5 Description of Operation
REGIUS MODEL 190 Service Manual Ver.1.00 2004.11.01
1.5.3 Initializing Sequence
Initializing sequence will be completed by turning ON the power breaker and pressing goperation" button of the
REGIUS Model 190.
Use the dummy SCB2 software to check mechanical operations. Refer to Refer to "3.3 Verification of Initializing
Sequence".
1.5.4 Erase Operation
Erase operation (both ERASE MODE 1 and ERASE MODE 2) follows the same sequence as the normal opera-
tion. Erasing will be completed in step 7 of "1.5.2 Normal Operation".
1 Insertion Slot Shutter Initialization of the insertion slot shutter is implemented.
2 Justification Assy Justification assy moves to HP.
3 Transport Unit Transport unit moves to HP.
4 Elevator Stand Elevator stand moves to HP, and initialization is implemented. After completing ini-
tialization, the elevator stand moves to receive position.
5 Subscanning Unit Initialization of the subscanning unit is implemented.
6 Transport Unit Initialization of the transport unit is implemented.
7 Elevator Stand Elevator stand moves to HP.
8 Lock-Release Motor Lock-release motor is locked.
