A.1 SCB2 Dummy Program Screens
REGIUS MODEL 190 Service Manual Ver.1.00 2004.11.01
A.1 SCB2 Dummy Program Screens
A.1.1 Main Window
The main window will appear right after the start up of the dummy SCB2 program.
Menu Menu Item Description
File Send Log (S)... N/A at present.
End Log (E) N/A at present.
Exit Dummy SCB2 (X) Exit the "Dummy SCB2 Program".
Set Up Communication Set Up (C)... Displays the "Communication Set Up" dialogue, and enables
to change the communication speed and COM port. (p.171)
SCB2 Set Up (S)... Displays "SCB2 Set Up" dialogue, and enables to change
various parameters for communication with MCB2. (p.173)
Font (F)... Changes the fonts which are displayed on the main window.
