1.1 Principal Specifications
REGIUS MODEL 190 Service Manual Ver.1.00 2004.11.01
1.1 Principal Specifications
1.1.1 Reading the Image
• Image Data
Service cassettes
Note : Except the USA
Read image sizes
In situations where the
read image data sent
from the REGIUS 190 is
larger than this read
area, it will be necessary
for the number of pixels
shown here to be
extracted by the
receiving device.
Cassette
Read Size
(mm)
Pixels
at 175ıı
ıı
at 87.5ıı
ıı
Note2
at 43.75ıı
ıı
14" x 17"
352.0 x 428.5 2010 x 2446 4020 x 4892 -
14" x 14"
352.0 x 352.0 2010 x 2010 4020 x 4020 -
11" x 14"
275.0 x 352.0 1570 x 2010 3140 x 4020 -
10" x 12"
250.5 x 301.5 1430 x 1722 2860 x 3444 -
8" x 10"
199.5 x 250.5 1140 x 1430 2280 x 2860 -
24 x 30cm
(
mammography
)
Note1
296.5 x 238.0 - 3388 x 2720 6776 x 5440
18x 24cm
(
mammography
)
Note1
237.0 x 177.0 - 2709 x 2023 5416 x 4040
15 x 30cm
296.5 x 146.5 1694 x 836 3388 x 1672 -
Note1 : Except the USA
Note2 : Needs optional license for 43.75µm read capability
Cassette Type Dimensions (mm)
W x H Thickness ≥≥
≥≥
14" x 17" 384 x 460 14
14" x 14" 384 x 384 14
11" x 14" 308 x 384 14
10" x 12" 282 x 333 14
8" x 10" 231 x 282 14
24 x 30cm (
mammography
)
Note
328 x 255 14
18 x 24cm (
mammography
)
Note
268 x 195 14
15 x 30cm 328 x 178 14
