132
4.1 Troubleshooting for Electrical Control & Communication
REGIUS MODEL 190 Service Manual Ver.1.00 2004.11.01
4.1.2 Power Supply On/Off Problems
Possible errors that may arise when the power is turned ON/OFF.
Cause Remedy
1) Even though the Operation button is
pressed, no operation takes place whatso-
ever (and the LED does not turn on)
Refer to "• Analysis Procedure of Power Failure (unable to
turn on the device) p.133".
2) When in Ready condition, pressing and hold-
ing "operation" button to terminate the pro-
cessing only put out the LCD panel but the
LED keep flashing.
Tu rn off the breaker of REGIUS 190.
3) Operation button has been pressed before
the JM is started up.
24000 error will occur; however, the JM will be automatically
connected as soon as it has been started up and the condi-
tion for normal reading will be achieved.
4) Power-supply off operation is not started
even though Operation button is pushed dur-
ing occurrence of an error.
Tu rn off the breaker of REGIUS 190.
5) Operation button has been pressed during
reading by the REGIUS.
• The image in reading process will be transferred to the
REGIUS Console.
• The REGIUS 190 will be automatically shut down after
completing the image transfer. Restart the REGIUS 190.
6) Sleep operation does not proceed correctly. Review the Relation setting for the JM.
7) Even though the REGIUS Console starts up,
the REGIUS 190 does not.
Check the status of the operation lamp.
• If the operation lamp is not on, it indicates that the REGIUS
190’s power is off, and the operation button should be pressed
to startup this device.
• If the operation lamp is on, shutdown the device using the oper-
ation button first, and then start it up again.
8) During image reading, the door is opened
and closed, or a breaker is turned off.
During image reading, if the plate adopts standby condition
in the Reader as a result of power off or the like, restoration
in that condition will result only in an error and the back plate
will not be lowered. Follow the procedures below to remove
the back plate.
1) Open the door, remove only the cassette's front plate only.
2) Restart.
3) After an error will be displayed, open the front door, and remove
from the cassette absorption plate, the back plate that has been
lowered.
To Next Page
