Konica Minolta REGIUS 190 - Mechanical Control Error Codes

151
4.4 Error Code
REGIUS MODEL 190 Service Manual Ver.1.00 2004.11.01
4.4.2 Mechanical Control Error Codes
04001 ~ 04069 indicates an error occurred on the sensors.
Error
code
Error name Error description Action
04001 Feed HP sensor NG A time-out occurred for ON or OFF
detection by the Feed HP sensor
while the transport unit is moving
to its receiving position.
Check MCB2:CN11-, pins 32 through 34
(HP sensor) and MCB2:CN15 (Trans-
portation Motor)
04011 Feed Escape Position
sensors NG (at initial-
ization)
A time-out occurred for ON detec-
tion by the Feed Escape Position
sensor while the transport unit is
moving to escape position.
Check MCB2:CN11-, pins 35 through 37
(Feed Escape Position sensors) and
MCB2:CN15 (Transportation Motor)
04012 Feed Escape Position
sensors NG (while
moving to absorption
position)
1) The Feed Escape Position sen-
sor was already ON at the start
of motion by the transport unit
from the receive position to the
absorption position.
2) A limit-over occurred for ON
detection by the Feed Escape
Position sensor during motion
by the transport unit from the
receive position to the absorp-
tion position.
Check MCB2:CN11-, pins 35 through 37
(Feed Escape Position sensors) and
MCB2:CN15 (Transportation Motor)
04013 Feed Escape Position
sensors NG (while
moving to escape
position)
A limit-over occurred for OFF
detection by the Feed Escape Posi-
tion sensor during motion by the
transport unit from the absorption
position to the escape position.
Check MCB2:CN11-, pins 35 through 37
(Feed Escape Position sensors) and
MCB2:CN15 (Transportation Motor)
04014 Feed Escape Position
sensors NG (while
moving to eject posi-
tion 1)
A limit-over occurred for OFF
detection by the Feed Escape
Position sensor during motion by
the transport unit from the absorp-
tion position to the escape posi-
tion.
Check MCB2:CN11-, pins 35 through 37
(Feed Escape Position sensors) and
MCB2:CN15 (Transportation Motorr)
04015 Feed Escape Position
sensors NG (while
moving to eject posi-
tion 2)
During motion by the transport unit
from the absorption position to the
eject position, ON --> OFF detec-
tion by the Feed Escape Position
sensor occurred within 70 mm
from the absorption position.
Check MCB2:CN11-, pins 35 through 37
(Feed Escape Position sensors) and
MCB2:CN15 (Transportation Motor)
04021 Justification R/L sen-
sor NG (at reading)
1) The Justification Sensor was
OFF after the completion of jus-
tification operation during cas-
sette intake.
2) The justification sensor was
OFF after closing of the inser-
tion slot shutter during cas-
sette take-in.
• Check MCB2:CN11-, pins 9 through
11 (Justification Sensor- L);
MCB2:CN11-, pins 12 through 14
(Justification Sensor-R); and
MCB2:CN17 (Justification Motor)
• Check the loose of the drive pulley
Refer to "2.4.3 Replacement of the
Justification Motor (PM2), p.55" and
"3.8 Checking and Adjusting the
Justification Allowance, p.124"
