EagleEye Director II Camera System Diagnostics
Most diagnostic information is available on both the web and the local interface, but some information is
specific to one or the other interface. From the web interface, go to Diagnostics > Audio and Video
Tests > Camera Tracking.
The screen includes the following diagnostic information for your camera system.
Diagnostic Screen Description
Speaker Test Tests the audio cable connections. A 473 Hz tone indicates that
the local audio connections are correct.
If you run a test during a call, people on the far site also hear the
test tone.
If you run the test from the system web interface during a call, the
people at the site you are testing hear the tone, but you don’t.
If you run the test from the system web interface during a call, the
people at the site you are testing will hear the tone, but you will
not.
Audio Meters Measures the strength of audio signals from ten internal
microphones, far-site audio, and any device connected to the
audio line in.
Meters function only when the associated input is enabled.
Note: Some audio meters are unavailable when a SoundStructure
digital mixer is connected to the room system.
Configuring a Camera or Camera Control System
Polycom, Inc. 175
