Anti-Condensation Heater
SM 2-73 D037/D038/D040/D041
Installaion
2.19 ANTI-CONDENSATION HEATER
2.19.1 INSTALLATION PROCEDURE
This heater is supplied as a spare part.
1. Rear cover ( Section: "Rear Cover" in the "Replacement and Adjustment" section)
2. Open the ARDF or platen cover.
3. Glass cover [A] (stepped screw x 4)
4. Scanner right cover [A] ( x 2)
