PM Parts Settings
SM 3-3 D037/D038/D040/D041
Preventive
Maintenance
*
1
: Only if the toner collection bottle is replaced before the machine detects
near-full.
For the following units, there is a new unit detection mechanism. It is not necessary to reset
PM counters.
Development unit
PCU/ ITB Toner Collection Bottle (if full or near-full)
3.2.2 AFTER INSTALLING THE NEW PM PARTS
1. Turn on the main power switch.
2. Output the SMC logging data with SP5-990-004 and check the counter values.
3. Make sure that the PM counters for the replaced units are “0” with SP7-803. If the PM
counter for a unit was not reset, then reset that counter with SP 7-804.
4. Make sure that the exchange counter counts up with SP7-853.
5. Make sure that the counters for the previous units (SP7-906) on the new SMC logging
data list (from step 2 above) are equal to the counters (SP7-803) for these units on the
previous SMC logging data list (the list that was output in the “Before removing the old
parts” section).
6. Make sure that the unit replacement date is updated with SP7-950.
3.2.3 PREPARATION BEFORE OPERATION CHECK
1. Clean the exposure glasses (for DF and book scanning).
2. Enter the user tools mode.
3. Do the “Automatic Color Calibration “(ACC) for the copier mode & printer mode as
follows:
Print the ACC test pattern (User Tools > Maintenance > ACC > Start).
Put the printout on the exposure glass.
Put 10 sheets of white paper on the test chart. This ensures the precise ACC
adjustment.
Close the ARDF or the platen cover.
Press “Start Scanning” on the LCD. Then, the machine starts the ACC.
4. Exit the User Tools mode, and then enter the SP mode.
5. Do the “Forced line position adjustment” as follows.
First do SP2-111-3 (Mode c).
Then do SP2-111-1 (Mode a).
To check if SP 2-111-1 was successful, watch the screen during the process. A
message is displayed at the end. Also, you can check the result with SP 2-194-10
to -12.
