Copier Installation
SM 2-13 D037/D038/D040/D041
Installaion
6. Remove the cover sheet [A] from the black PCDU.
7. Reinstall the black PCDU into the mainframe ( x 2).
8. Reinstall the PCDU toner collection bottle.
9. Shake each toner bottle five or six times.
10. Slide the toner bottles in toner bottle cartridges, then turn each one to the right
(clockwise).
11. Close the front door.
Paper Trays
1. Pull each paper tray [A] out. Then adjust the side guides and end guide to match the
paper size.
 To move the side guides, first pull out the tray fully. Then push down the green
lock at the rear inside the tray.
