Installation Requirements
D037/D038/D040/D041 2-2 SM
2.1.3 MACHINE SPACE REQUIREMENTS
 This machine, which uses high voltage power sources, can generate ozone gas.
High ozone density is harmful to human health. Therefore, the machine must be
installed in a well-ventilated room.
A: Over 100 mm (3.9")
B: Over 100 mm (3.9")
C: Over 100 mm (3.9")
D: Over 100 mm (3.9")
Put the machine near the power source with the clearance shown above.
2.1.4 POWER REQUIREMENTS
 Insert the plug firmly in the outlet.
 Do not use an outlet extension plug or cord.
 Ground the machine.
1. Input voltage level:
 120 V, 60 Hz: More than 12 A
 220 V to 240 V, 50 Hz/60 Hz: More than 8 A
2. Permissible voltage fluctuation: ±10 %
3. Do not put things on the power cord.
