SC Tables
D037/D038/D040/D041 4-4 SM Appendix
Class 1 Section SC Code Detailed section
860 - Hard disk
880 - Unique for a specific model
900 - Counter
920 - Memory
9XX Others
990 - Others
4.1.2 SC1XX: SCANNING
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
Exposure lamp error
The peak white level is less than 64/255 digits (8 bits) when scanning
the shading plate.
 Exposure lamp defective
 Lamp stabilizer defective
 Exposure lamp connector defective
 Standard white plate dirty
 Scanner mirror or scanner lens out of position or dirty
101 D
1. Check and clean the scanner mirror(s) and scanner lens.
2. Check and clean the shading plate.
3. Replace the exposure lamp.
4. Replace the lamp stabilizer.
5. Replace the scanner mirror(s) or scanner lens.
To Next Page
