Platen Cover Installation (G329)
SM 2-33 D037/D038/D040/D041
Installaion
2.8 PLATEN COVER INSTALLATION (G329)
1. Install the stud screws [A] ( x 2) on the top cover as shown.
2. Position the platen cover bracket [B] on the heads of the stud screws, and slide the
platen cover [C] to the left.
