Image Adjustment
SM 4-13 D037/D038/D040/D041
Replacement
& Adjustment
Item to Adjust Level on the C-4 chart (K) Adjustment Standard
For adjusting K Highlight: SP4-914-001
Text parts of the test pattern cannot be printed clearly after you adjust “shadow” as
shown above. At this time, check if the 5 line/mm pattern at each corner is printed
clearly. If it is not, adjust the offset value of “shadow” again until it is.
Printer Mode
There are six adjustable modes (select these modes with printer SP1-102-001):
1200 x 1200 photo mode
1200 x 1200 text mode
2400 x 600 photo mode
2400 x 600 text mode
1800 x 600 photo mode
1800 x 600 text mode
600 x 600 photo mode
600 x 600 text mode
K C M Y
Highlight
Shadow
Middle
IDmax
SP1-104-1
SP1-104-2
SP1-104-3
SP1-104-4
SP1-104-21
SP1-104-22
SP1-104-23
SP1-104-24
SP1-104-41
SP1-104-42
SP1-104-43
SP1-104-44
SP1-104-61
SP1-104-62
SP1-104-63
SP1-104-64
- Adjustment Procedure -
1. Do ACC for the printer mode.
2. Turn the main power off and on.
3. Enter SP mode.
4. Select “Printer SP”.
5. Select SP1-102-001. Then select the necessary print mode to adjust.
6. Choose SP1-103-1 to print out a tone control test sheet if you want to examine the
image quality for these settings.
7. Adjust the color density with SP1-104. Compare the tone control test sheet with the C4
To Next Page
