Fusing
SM 4-91 D037/D038/D040/D041
Replacement
& Adjustment
13. Bearings [B] of the fusing roller ( x 1 each)
14. Fusing belt [A] with rollers
15. Fusing belt [A]
4.11.9 HEATING, FUSING AND TENSION ROLLER
If you install a new fusing roller, set SP 3902-015 to "1" before you start this procedure.
If you do this, then the machine will reset the PM counter for the fusing unit
automatically, after you turn the power on again.
1. Fusing belt with rollers ( Section: Fusing Belt)
