Service Program Mode
D037/D038/D040/D041 5-6 SM
5.1.4 REMARKS
Display on the Control Panel Screen
The maximum number of characters which can show on the control panel screen is limited
to 30 (H-model)/ 17 (L-model) characters. For this reason, some of the SP modes shown
on the screen need to be abbreviated. The following are abbreviations used for the SP
modes for which the full description is over 30 (H-model)/ 17 (L-model) characters.
Paper Weight
Thin paper: 52-59.9 g/m
2
Plain Paper1: 60-74 g/m
2
, 16-20lb.
Plain Paper2: 74.1-90 g/m
2
, 20-24lb.
Middle Thick: 90.1-105 g/m
2
, 24-28lb.
Thick Paper 1: 105.1-169 g/m
2
, 28.5-44.9lb.
Thick Paper 2: 169.1-210 g/m
2
, 45-56lb.
Thick Paper 3: 210.1-256 g/m
2,
56lb-68lb
Paper Type
N: Normal paper
MTH: Middle thick paper
TH: Thick paper
Paper Feed Station
P: Paper tray
B: By-pass table
Color Mode [Color]
[K]: Black in B&W mode
[Y], [M], or [C]: Yellow, Magenta, or Cyan in Full Color mode
[YMC]: Only for Yellow, Magenta, and Cyan
[FC]: Full Color mode
[FC, K], [FC, Y], [FC, M], or [FC, C]: Black, Yellow, Magenta, or Cyan in full color mode
Print Mode
S: Simplex
D: Duplex
Process Speed
L: Low speed (60 mm/s)
M: Middle speed (120 mm/s)
Others
The following symbols are used in the SP mode tables.
FA: Factory setting
(Data may be adjusted from the default setting at the factory. Refer to the factory setting
