Ricoh Aficio MP C2030 Service Manual

Internal Finisher (D429)
SM 2-43 D037/D038/D040/D041
Installaion
2.12.2 INSTALLATION PROCEDURE
 Unplug the copier power cord before starting the following procedure.
Preparing before Installing the Internal Finisher
1. Remove all tapes from the internal finisher.
2. Remove the inverter tray [A].
3. Open the front door [B].
4. Remove the lower inner cover [A].
5. Press the ITB lock lever [B] and turn it up as shown above.
