Ricoh Aficio MP C2030 Service Manual

Overview
D037/D038/D040/D041 2-2 SM Appendix
7. Paper exit roller
8. Junction gate
9. Duplex unit
10. Fusing unit
11. PTR (Paper transfer roller) unit
12. Registration roller
13. Vertical transport roller 1
14. By-pass feed roller
15. Feed roller: T1
22. Drum unit
23. Development unit
24. ITB cleaning unit
25. ITB roller
26. Toner bottle
27. ITB (Image Transfer Belt) unit
28. Inner Tray
2.1.2 PAPER PATH
With options
1. DF path
2. Exit path: Straight feed out
6. By-pass tray path
7. Vertical transport path: Tray 2

Ricoh Aficio MP C2030 Specifications

General

Brand	Ricoh
Model	Aficio MP C2030
Category	All in One Printer
Language	English
