Troubleshooting Guide
D037/D038/D040/D041 6-6 SM
3. An error ("1") occurs in the SP1-803-006.
[Setting values of the following SPs + input value with SP1-803-001] > motor speed
adjustable range
e.g.) 3.5 (SP1-801-001) + 1 (SP1-803-001 to -003) = 4.5
In this case, "4.5" is over the maximum adjustable value ("4") of the SP1-801-025. As a
result, the result of the motor speed adjustment issues "1" (error).
 Adjust the settings of the SP1-830-001 to -003 so that the total value (motor speed
setting value + input value) is within the adjustable range for each motor described
below.
SP No. Max. Min. Title
SP1-801-001 4 -4 Regist Mot:60:Thick
SP1-801-004 4 -4 Bk OpcDevMot:60:Thick
SP1-801-008 6 -6 Fusing Mot:60:Thick
SP1-801-010 4 -4 TransferMot:60:Thick
SP1-801-011 2 -2 Feed1:CW60:Thick
SP1-801-013 2 -2 Feed1:CCW60:Thick
SP1-801-015 2 -2 Feed2:CW60:Thick
SP1-801-017 2 -2 Feed2:CCW60:Thick
SP1-801-019 2 -2 By-pass:60:Thick
SP1-801-021 2 -2 Inverter:CW60:Thick
SP1-801-023 2 -2 Inverter:CCW60:Thick
6.3.2 TRAPEZOID IMAGE ADJUSTMENT
Before Adjusting the Trapezoid Image
1. Enter SP2-109 and print out the test pattern 14 (Trimming Area).
To Next Page
