Ricoh Aficio MP C2030 Service Manual

Optional Unit Combinations
SM 2-3 D037/D038/D040/D041
Installaion
2.2 OPTIONAL UNIT COMBINATIONS
2.2.1 MACHINE OPTIONS
Options
No.
D037/D040 D038/D041
Remarks
1 2-tray paper feed unit 2-tray paper feed unit
2 1-tray paper feed unit 1-tray paper feed unit
3 Caster table Caster table
One from No.1 or No.2
(No. 2 requires No. 3)
4 Platen cover Platen cover
5 ARDF ARDF (Standard)
One from No.4 or No.5
6 1-bin tray unit 1-bin tray unit
7 - Shift tray
8 Side Tray Side Tray
9 - Internal finisher
If No 9 is installed, then
No 6 and/or No 7 cannot
be installed.
10 - *Punch kit (4 types)
No. 9 required; One of
the types
11 Fax unit Fax unit -
12 - Memory Unit (32M)* Fax unit required
*: Child options (Child options require a parent option.)
Rev. 02/2009
