System Service Mode
SM Appendix 9-345 D037/D038/D040/D041
Appendix:
SP Mode
Tables
A3 11" x 17" O O O O O 00000011
B4 10" x 14" O O X O O 00000011
F4
8.5" x 13", 8.25" x
13", or 8" x 13"
SP 5126 controls the
size that is detected
8.5” x 14” O X X O O 00000011
A4 LEF 8.5" x 11" O O O X X 00000000
B5 LEF - O O X X X 00000000
A4 SEF 11" x 8.5" O X X O X 00000010
B5 SEF - X X X O X 00000010
A5 LEF/ SEF
5.5" x 8.5",
8.5" x 5.5"
X X X X X 00000000
Table 4: Paper Size Switch (Tray 3/ 4)
"Bit 0" is used for tray set detection. 0: Set, 1: Not set
0: Not Interrupted, 1: Interrupted
Models Bit
North America Europe/Asia 3 2 1 0
11" x 17" SEF*
1
(A3 SEF)
A3 SEF*
1
(11" x 17" SEF)
0 1 1 0
8.5" x 14" SEF
*2
(B4 SEF)
B4 SEF
*2
(8.5" x 14" SEF)
1 1 1 0
A4 SEF A4 SEF 1 0 0 0
B5 SEF B5 SEF 0 0 1 1
8.5" x 11" SEF 8.5" x 11" SEF 0 0 0 0
