5-l.
GENERAL DESCRIPTION
VEHICLE EMISSION CONTROL INFORMATION LABEL
The Vehicle Emission Control Information Label is located under hood. The label contains important
emission specifications and setting procedures, as well as a vacuum hose schematic with emission compo-
nents identified.
When servicing the engine or emission systems, the Vehicle Emission Control Information Label should be
checked for up-to-date information.
1. Emission control label
2. Hood
EMISSION HOSE ROUTING
EGR VACUUM MODULATOR
THERM0 VALVE
\/-
I
I
EGR-VALVE
-/------
BVSV
Rr,
JET
/VACUUM MOTOR
Fig.
5-
1-2 Vehicle emission control information label
5-4
