Gear Shift Control Lever Seat
Make sure to fit control lever seat
@I
into
gear shift lever case so that locating bolt
@
goes in the groove of control lever seat. And
fit wave washer
@J
with its projection surface
directed upward.
--
Fig. 12-15
Tightening Torque
(h
Greasing point
To be tightened to:
N-m
kg-m
lb-ft
(jj
Lever case cover
bolt
4
-
7 0.4 -0.7
3.0-
5.0
0
Reverse select
pin screw
25
-
35 2.5
-
3.5 18.5
-
25.0
0
Lever boot
bolt
4-
7
0.4-
0.7
3.0-
5.0
@
Lever locating
bolt
14-20 1.4-2.0
10.5-
14.0
0
Lever case
’
bolt
18-28 1.8-2.8 13.5-20.0
a
Low speed
select pin bolt
4-7 0.4
-
0.7 3.0
-
5.0
APPLY
to
@
:
Between gear shift lever boot No. 1 and lever
case cover
@
:
Between gear shift lever and lever seat
Between gear shift lever and lever case
Gear shift lever locating bolt
*
Grease to be used for each greasing point is
SUZUKI SUPER GREASE A(99000-25010).
*
If gear shift lever locating bolt is removed
from case, be sure to apply locking agent
(THREAD LOCK CEMENT SUPER “1333B”
99000-32020) to bolt thread for reinstalla-
tion.
Fig. 12-16
12-6
