Wire color
G/R . . .
Green/Red Or . Orange
0 . . . . .
Black
BI/B . Blue/Black
0rlB . . .
Brown/Black w . White
Y/B . . .
Yellow/Black
Y/R . Yellow/Red
B/W . .
Black/White
G/Y . .
Green/Yellow
W/R .
White/Red
Y/W . . Yellow/White
RIB .
Red/Black
R/Y . Red/Yellow
G
. . . Green
R/G . . .
Red/Green
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
50,000 mile, 80,000 mile and
11. 4WD light
100,000 mile sensor switch
12. Noise’suppressor
Turn signal pilot light (Lb
13. Turn signal pilot light (RI
Cancel switch
14. Beam pilot light
Seat belt warning light
15. Fuel level meter
Brake oil level warning light
16. Temp. meter
and parking brake light
17. Illumination light
Charge light”
18. Tachometer
Engine oil pressure light
19. Seat belt warning buzzer
“CHECK ENGINE" light
20. Combination meter
Diode
21. Check switch
Seat belt relay
[Combination meter without tachometer]
[Combination meter with tachometer]
4. TEMP. meter
5. Meter print plate
6. Bulb
7. Socket
Combination meter
Fig. 21-1
8. Tachometer
REMOVAL AND INSTALLATION
1. Disconnect battery negative cable.
2. Remove instrument lower panel.
3. Lower steering column.
4. Remove combination meter cover.
5. Disconnect speedometer cable and wire
harness coupler.
7. To install combination meter, reverse above
removal procedure.
6. Remove combination meter.
Fig. 21-2
2. Speedometer
3. Fuel Meter
21-3
