Suzuki Samurai 1987 User Manual

Fig. 13-72
Fig. 13:74 Main shaft and input shaft assembly
Transmission Lower Case and Upper Case
1) With counter shaft ass’y, reverse idle gear
and reverse gear shaft installed in lower
case, check to ensure that bearing stopper
rings @ are fitted in both sides of lower
case as shown below.
Also check for 2 knock pins 0.
Fig. 13-75
Fig. 13-73
2) Make sure that mating surfaces of both lower
and upper cases are clean.
3) Install main shaft and input shaft ass’y in
lower case.
Fig. 13-76
13-22
