2) Cut oil seal in place with scissors or a knife,
and take it off.
3) Cut replacement oil seal at one place with
scissors or a knife as shown in below figure.
4) Install the seal in oil seal retainer, bringing
the cut portion to top side and locating it
about 30 degrees off the matching face of
oil seal retainer.
5) Apply grease to inside of oil seal. Apply
sealing compound to mating face all around:
this is for preventing entry of water.
. SEALING COMPOUND “CEMEDINE”
366E (99000-31090)
. SUZUKI SUPER GREASE H
99000-25120).
Apply grease
Apply sealer
, n
Rear Wheel Bearing
1) Check wheel bearings for wear. When measur-
ing thrust play, apply a dial gauge to drum
center.
Thrust play Limit Rear
0.8 mm (0.03 in.)
1
When measurement exceeds limit, replace
bearing.
2) By rotating wheel actually, check wheel
bearing for noise and smooth rotation. If it
is defective, replace bearing.
Bolts and Nuts
Check following bolts and nuts for tighteness
and retighten them to specified torque as
necessary.
Fastening parts
Tightening torque
@ Shackle pin nut
@ Leaf spring nut
@ Leaf spring U bolt nut
_ Refer to "RECOM-
@ Wheel nut
6) Tighten joint seat securing bolts to specified
torque.
Fig. 17-3-16
Fig. 17-3-17
17-24
Fig. 17-3-18
MENDED TORQUE
SPECIFICATIONS"
in this section
