After removing oil seal, remove circlip and drive
bearing out of front case by using bearing
installer (special tool).
Bearing installer 0 : (09913-76010)
Fig. 14-19
Transfer Center Case
Remove bolts fastening center case and rear
case together.
Do not loosen bolt @ at this point.
By tapping rear case and output rear shaft with.
a plastic hammer, separate center and rear case.
Fig. 14-22
Given below are procedures for disassembling
component parts of center case as separted from
rear case.
1) Loosen gear shift locating spring plug and
take out spring and locating ball.
Fig. 14-23
14-9
Fig. 14-20
Fig. 14-21
