To decrease sharpening
1. Click the Copy Services button, then select the Image Quality tab.
2. Select the Image Adjustments button.
3. Decrease the amount of sharpnessby moving the slider controlto the left, or entering alowernumber
in the text box to the right of the slider control.
4. Click the Copy button when satisfied with your adjustments.
Tip
If you have programmed and run a job, and received unexpected results, ensure that the system-wide
settings are all set back to their defaults by clicking Clear All or Reset in the user interface. Then proceed
to do job programming pertinent to your job.
Removing Background Artifacts (when scanning or copying)
If your original document is on colored stock, the output copy may display background artifacts.
Background is only detected on the first few mm of the lead edge. Ensure the lead edge is not solid black
and the document is registered against the registration edge indicated on the platen.
To remove background artifacts
1. In the Xerox Nuvera user interface, click the Copy Service button.
2. Click the Image Quality tab.
3. Click the Image Adjustments button.
4. Make sure the Background Suppression Normal checkbox is enabled. It is on by default.
Tip
If you have programmed and run a job, and received unexpected results, ensure that the system-wide
settings are all set back to their defaults by clicking Clear All or Reset in the user interface. Then proceed
to do job programming pertinent to your job.
Removing Image Show Through (when scanning or copying)
When scanning translucent originals, sometimes the image on the back side of the page is detected,
resulting in a scan of the image on the other side of the sheet (see figure).
Figure 23: Example of Show Through
To correct image show through
1. In the Xerox Nuvera user interface, click the Copy Services button.
2. Click the Image Quality tab.
Xerox
®
Nuvera
®
18-10
User Guide and Training Aid (UGTA)
Problem Solving
