TROUBLESHOOTING
MM9000 Rev C.8 01/13 Page 157
MM9000 ClearCommand User Manual
Troubleshooting
10.8.3 Basic Control System Error Codes
10 Troll Command Open The Troll Proportional Solenoid should be drawing current but is not.
Table 10-6: Basic Control System Error Codes
Error
No.
Title Description
13
Station No.1
Faulted High
Station No.1 Control Head’s lever position is out of range.
The input appears to be too high.
14
Station No.2
Faulted High
Station No.2 Control Head’s lever position is out of range.
The input appears to be too high.
15
Station No.3
Faulted High
Station No.3 Control Head’s lever position is out of range.
The input appears to be too high.
16
Station No.4
Faulted High
Station No.4 Control Head’s lever position is out of range.
The input appears to be too high.
17
Station No.5
Faulted High
Station No.5 Control Head’s lever position is out of range.
The input appears to be too high.
18
Station No.6
Faulted High
Station No.6 Control Head’s lever position is out of range.
The input appears to be too high.
19
Station No.7
Faulted High
Station No.7 Control Head’s lever position is out of range.
The input appears to be too high.
20
Station No.8
Faulted High
Station No.8 Control Head’s lever position is out of range.
The input appears to be too high.
21
Station No.9
Faulted High
Station No.9 Control Head’s lever position is out of range.
The input appears to be too high.
22
Station No.10
Faulted High
Station No.10 Control Head’s lever position is out of range.
The input appears to be too high.
23
Station No.1
Faulted Low
Station No.1 Control Head’s lever position is out of range.
The input appears to be too low.
24
Station No.2
Faulted Low
Station No.2 Control Head’s lever position is out of range.
The input appears to be too low.
25
Station No.3
Faulted Low
Station No.3 Control Head’s lever position is out of range.
The input appears to be too low.
26
Station No.4
Faulted Low
Station No.4 Control Head’s lever position is out of range.
The input appears to be too low.
27
Station No.5
Faulted Low
Station No.5 Control Head’s lever position is out of range.
The input appears to be too low.
28
Station No.6
Faulted Low
Station No.6 Control Head’s lever position is out of range.
The input appears to be too low.
29
Station No.7
Faulted Low
Station No.7 Control Head’s lever position is out of range.
The input appears to be too low.
Table 10-5: Troll Solenoid Control System Error Codes
Error
No.
Title Description
