2.5 Station Transfer
Command can be transferred as follows:
A The Station-in-Command’s lever(s) may be left in any position.
B Place the Control Head’s lever(s) of the receiving Station in the Neutral/Idle detent position (refer to
Figure 2-7: Remote Stations Before Transfer of Command)
C At the Station taking command (Receiving Station), depress and hold the transfer button for 1/2
second (refer to Figure 2-8: Remote Station Transfer after Transfer of Command).
• The red LED indicator light at the receiving Station’s Control Head will illuminate, indicating
that the Station has taken command.
• The red LED indicator light will go OFF at the transferring Station’s Control Head, indicating
that the Station no longer is in command.
D The commanded positions of the Throttle and Clutch will remain unchanged for one second after the
red LED lights. This allows the operator time to move the Control Head’s lever(s) to a position
approximately matching the last Station, which will allow the vessel to maintain present speed and
direction.
2.6 Proportional Pause
The proportional pause provides a means of safely reversing the vessel’s direction. A variable pause is
introduced into the clutch command signal to allow time for the engine RPM’s to drop to Idle and for the
vessel’s speed through the water to slow. This pause is set during Section 7: Sea Trials.
WARNING: Personal Injury may result if this message is disregarded.
Figure 2-7: Remote Stations Before Transfer of Command Figure 2-8: Remote Station Transfer after Transfer of
Command
10238
Station-in-Command
Red Indicator
Light “on”
Station 1
Cruise Speed
10161
Receiving Station
Station 2
Red Indicator
Light “off”
Neutral Detent
10238
Station no longer in Command
Red Indicator
Light “off”
Station 1
10161
Station-in-Command
Depress
Transfer
Button
Station 2
Red Indicator
Light “on”
