ZF MM9000 User Manual

160 EN 3340.758.003a - 2014-11
TROUBLESHOOTING
MM9000 Rev C.8 01/13 Page 160
MM9000 ClearCommand User Manual
Troubleshooting
10.9 Basic Problem Causes And Solutions
The following table lists the various Error Codes and provides possible causes and solutions. Error Codes
appearing on the Port side Processor’s Display LED are port side errors and vice versa. The Causes and
Solutions provided are the most likely, but are not the only possible causes for the Errors Codes listed.
10.9.1 Basic Control System Problem Causes and Solutions
Table 10-9: Basic Control System Problem Causes and Solutions
Error
No.
Causes Solutions
13
a. Station No.1 Control Head is defective. a. Replace Station No.1 Control Head.
b.
No continuity between pin 5’s of the Control Head
Harness connectors.
b.
Ensure that the red conductor is properly crimped
to pin 5 at both connectors.
c. Control Head jumper (pin 3 to 5 or 7) is missing. c.
Install a jumper from pin 3 to 5 on right hand and
3 to 7 on left hand Control Heads.
14
a. The Station No.2 Control Head is defective. a. Replace Station No.2 Control Head.
b.
No continuity between pin 5’s of the Control Head
Harness connectors.
b.
Ensure that the red conductor is properly crimped
to pin 5 at both connectors.
c. Control Head jumper (pin 3 to 5 or 7) is missing. c.
Install a jumper from pin 3 to 5 on right hand and
3 to 7 on left hand Control Heads.
15
a. The Station No.3 Control Head is defective. a. Replace Station No.3 Control Head.
b.
No continuity between pin 5’s of the Control Head
Harness connectors.
b.
Ensure that the red conductor is properly crimped
to pin 5 at both connectors.
c. Control Head jumper (pin 3 to 5 or 7) is missing. c.
Install a jumper from pin 3 to 5 on right hand and
3 to 7 on left hand Control Heads.
16
a. The Station No.4 Control Head is defective. a. Replace Station No.4 Control Head.
b.
No continuity between pin 5’s of the Control Head
Harness connectors.
b.
Ensure that the red conductor is properly crimped
to pin 5 at both connectors.
c. Control Head jumper (pin 3 to 5 or 7) is missing. c.
Install a jumper from pin 3 to 5 on right hand and
3 to 7 on left hand Control Heads.
17
a. The Station No.5 Control Head is defective. a. Replace Station No.5 Control Head.
b.
No continuity between pin 5’s of the Control Head
Harness connectors.
b.
Ensure that the red conductor is properly crimped
to pin 5 at both connectors.
c. Control Head jumper (pin 3 to 5 or 7) is missing. c.
Install a jumper from pin 3 to 5 on right hand and
3 to 7 on left hand Control Heads.
18
a. The Station No.6 Control Head is defective. a. Replace Station No.6 Control Head.
b.
No continuity between pin 5’s of the Control Head
Harness connectors.
b.
Ensure that the red conductor is properly crimped
to pin 5 at both connectors.
c. Control Head jumper (pin 3 to 5 or 7) is missing. c.
Install a jumper from pin 3 to 5 on right hand and
3 to 7 on left hand Control Heads.
