MMC-345 Rev A.1 10/11 Page 241
MMC-345 43C Cable Conversion Kit
MMC-345 43C Cable Conversion Kit
43C Cable Conversion Kit
Figure 1: Actuator/Processor Preparation
Figure 2: Actuator/Processor Cable Installation
Rev Date Revision Description
A 8/03 Added 9000 Series.
A.1 10/11 Converted document name from MM13821 to MMC-345
CAUTION: Static electricity can destroy electronic components. Anytime the Actuator/Processor cover is off,
use an anti-static wrist strap and connect it to the Actuator/Processor frame. This will drain any static charge
you may have on your person.
NOTE: 43C cable and jam nut are supplied by others.
ZF Marine Propulsion Systems Miramar, LLC
12125 Harbour Reach Dr Ste B
Mukilteo, WA 98275
P - 425-583-1900
F - 425-493-1569
www.zf.com
