InteliLite 9 Global Guide
176
Subgroup: Stopping
Setpoint group Engine settings Related FW 1.1.0
Range [units] Idle / Nominal [-]
Default value Nominal Alternative config NO
Step [-]
Comm object 10046 Related applications AMF, MRS
Config level Advanced
Setpoint visibility Always
Description
Selects the function of the binary output IDLE/NOMINAL (PAGE 335) during engine cooling state.
Idle Cooling is executed at Idle speed and generator protections are switched off.
Nominal Cooling is executed at Nominal speed and generator protections are active.
Note: When ECU is connected the predefined value 900 RPM for Idle speed is requested.
Note: Binary output IDLE/NOMINAL (PAGE 335) must be configured and connected to speed governor.
Engine Idle speed must be adjusted on speed governor.
Cooling Speed
6 back to List of setpoints
Subgroup: Stopping Timers
Setpoint group Engine settings Related FW 1.1.0
Range [units] 0 .. 3 600 [s]
Default value 30 s Alternative config NO
Step 1 s
Comm object 8258 Related applications AMF, MRS
Config level Standard
Setpoint visibility Always
Description
Runtime of the unloaded gen-set to cool the engine before stop.
Cooling Time
6 back to List of setpoints
Setpoint group Engine settings Related FW 1.1.0
Fixed value 60 s
Description
Under normal conditions the engine must certainly stop within this period after the FUEL SOLENOID (PAGE
326) has been de-energized and the STOP SOLENOID (PAGE 345) energized. The stop solenoid remains
energized for the entire stop time period.
Stop Time
