Setpoint group Generator settings Related FW 1.1.0
Range [units]
0,0 .. Generator Underfrequency Wrn (page 196) [%]
Default value 85,0 % Alternative config NO
Step
0,1 % of Nominal Frequency (page 150)
Comm object 8298 Related applications AMF, MRS
Config level Standard
Setpoint visibility Always
Description
Threshold for generator phase L1 underfrequency.
Note: When there is no control of breakers, the type of protection is Sd not BOC.
Generator Underfrequency BOC
6 back to List of setpoints
Setpoint group Generator settings Related FW 1.1.0
Range [units]
Generator Underfrequency BOC (page 196) .. Generator Overfrequency Wrn (page 195)
[%]
Default value 85,0 % Alternative config NO
Step
0,1 % of Nominal Frequency (page 150)
Comm object 9689 Related applications AMF, MRS
Config level Standard
Setpoint visibility Always
Description
Threshold for generator phase L1 underfrequency.
Generator Underfrequency Wrn
6 back to List of setpoints
Setpoint group Generator settings Related FW 1.1.0
Range [units] 0,0 .. 600,0 [s]
Default value 3,0 s Alternative config NO
Step 0,1 s
Comm object 8297 Related applications AMF, MRS
Config level Standard
Setpoint visibility Always
Description
Delay for Generator Overfrequency BOC (page 195), Generator Overfrequency Wrn (page 195), Generator
Underfrequency Wrn (page 196) and Generator Underfrequency BOC (page 196) protection.
Generator <> Frequency Delay
6 back to List of setpoints
