Page #109 background image
InteliLite 9 Global Guide
109
Configuration set 1 Configuration set 2 Configuration set 3
Nominal Power Split Phase 1 (page
241)
Nominal Power 1 (page 241)
Nominal RPM 1 (page 239)
Nominal Frequency 1 (page 239)
Nominal Voltage Ph-N 1 (page 240)
Nominal Voltage Ph-Ph 1 (page 240)
Nominal Current 1 (page 242)
Connection Type 1 (page 242)
ECU Speed Adjustment 1 (page 253)
Nominal Power Split Phase 2 (page
245)
Nominal Power 2 (page 245)
Nominal RPM 2 (page 243)
Nominal Frequency 2 (page 244)
Nominal Voltage Ph-N 2 (page 244)
Nominal Voltage Ph-Ph 2 (page 244)
Nominal Current 2 (page 246)
Connection type 2 (page 246)
ECU Speed Adjustment 2 (page 255)
Nominal Power Split Phase 3 (page
249)
Nominal Power 3 (page 249)
Nominal RPM 3 (page 247)
Nominal Frequency 3 (page 248)
Nominal Voltage Ph-N 3 (page 248)
Nominal Voltage Ph-Ph 3 (page 248)
Nominal Current 3 (page 250)
Connection type 3 (page 250)
ECU Speed Adjustment 3 (page 257)
Configuration sets can be changed via logical binary inputs ALTERNATE CONFIG 2 (PAGE 295) and ALTERNATE
CONFIG 3 (PAGE 295). Configuration set 1 is active when there is no input activated. In case that inputs
ALTERNATE CONFIG 2 (PAGE 295) and ALTERNATE CONFIG 3 (PAGE 295) are active at the same time, the
configuration set 3 is took in account.
ALTERNATE CONFIG 2 (PAGE 295) ALTERNATE CONFIG 3 (PAGE 295) Active configuration set
0 0 1
1 0 2
0 1 3
1 1 3
5.4.22 E-Stop
Binary outputs for the control of some essential functions are internally wired as "safe", it means, that their
deactivation is directly bind with the dedicated Input E-STOP (not evaluated as the LBI in the controller). This
BO are fully configurable and are used e.g. for the Starter and Fuel control.
The emergency stop circuit must be secured.
No accidental activation on the PCB, circuit must disable the operation of the emergency stop.
The power supply of the associated binary outputs (BIN1 and BIN2) is supplied by the E-STOP input, not by
the + battery voltage.
Note: There is no difference int the way of configuration of all binary outputs. Binary outputs BO1 (Starter), BO2
(Fuel Solenoid) are intended for these functions (not dedicated).
There is a measuring of E-STOP input voltage analogically and setting the binary value (representing
emergency stop input level) based on comparison of the measured voltage to two analog levels, which are
derived from the controller supply voltage (battery voltage) perceptually.
