InteliLite 9 Global Guide
207
Setpoint group AMF settings Related FW 1.1.0
Range [units] Mains Fail / Gen Run [-]
Default value Gen Run Alternative config NO
Step [-]
Comm object 9850 Related applications AMF
Config level Advanced
Setpoint visibility
Conditioned by the setpoint Operation Mode (page 154)
Description
Setpoint adjust the behavior of opening MCB in AUTO mode when there is mains fail.
Mains Fail The command to open the MCB is given immediately after mains fail condition is evaluated.
If the mains will return into parameters after MCB was opened and before GCB is closed, timer
MCB Close Delay (page 202) is applied before MCB closing.
Gen Run MCB will be opened when engine will be running and it will be possible to transfer load from
Mains to gen-set (after stabilisation phase).
Note: This option should be used for MCBs using 230V control and not equipped with the undervoltage
coil.
MCB Opens On
6 back to List of setpoints
Group: General Analog Inputs
General Analog Input 1
Setpoint group General Analog Inputs Related FW 1.1.0
Range [units] the range is defined by analog sensor curve
Default value
the value is defined by
analog sensor curve
Alternative config NO
Step the step is defined by analog sensor curve
Comm object 9259 Related applications AMF, MRS
Config level Standard
Setpoint visibility Visible only if the logical analog input AIN PROT01 (PAGE 350) is configured
Description
Warning or history threshold level for AIN PROT01 (PAGE 350).
Note: These setpoints are used only if LAI AIN PROT01 (PAGE 350) is adjusted to required protection
type. Otherwise these setpoints are useless.
Analog Protection 1 Wrn
6 back to List of setpoints
