InteliLite 9 Global Guide
264
Value group Engine Related FW 1.1.0
Units Depends on ECU value
Comm object 10173 Related applications AMF, MRS
Description
This is one of the inputs, which are defined by ECU. Order of values depends on type of ECU.
Note: Usually there are engine speed[RPM], fuel rate[L/h], coolant temperature[°C], intake temperature
[°C], oil pressure[bar], boost pressure[bar], load[%], oil temperature[°C] etc.
ECU-BIN-EXT-1
6 back to List of values
Value group Engine Related FW 1.1.0
Units -
Comm object 12926 Related applications AMF, MRS
Description
Shows selected frequency of ECU. The value is calculated from setpoint Nominal Frequency (page 150)
If is Nominal Frequency (page 150) in range from 45 Hz to 54 Hz, is considered as 50 Hz application.
The value is set to 0.
If is Nominal Frequency (page 150) in range from 55 Hz to 65 Hz, is considered as 60 Hz application.
The value is set to 1.
ECU Frequency Select
6 back to List of values
Value group Engine Related FW 1.1.0
Units -
Comm object 10034 Related applications AMF, MRS
Description
Shows binary status (0 or 1) of ECU:
ECU Yellow Lamp
ECU Red Lamp
Wait To Start
ECU State
6 back to List of values
