ComAp InteliLite 9 User Manual

InteliLite 9 Global Guide
146
Setpoint group Basic settings Related FW 1.1.0
Range [units] 1 .. 5 000 [kW]
Default value 200 kW Alternative config Yes
Step 1 kW
Comm object 8276 Related applications AMF, MRS
Config level Standard
Setpoint visibility Always
Description
Nominal power of the gen-set. Generator Overload BOC (page 192) protection is based on this setpoint.
Note: This setpoint is used when setpoint Connection type (page 147) is adjusted to Monophase or
Splitphase or 3Ph3Wire or High Leg D or 3Ph4Wire or when Autodetect detects connection type as
3Ph3Wire or High Leg D or 3Ph4Wire.
Note: To lock this setpoint against editing you also have to lock setpoint Nominal Power 1 (page 241),
Nominal Power 2 (page 245) and Nominal Power 3 (page 249).
Nominal Power
6 back to List of setpoints
Subgroup: Current settings
Setpoint group Basic settings Related FW 1.1.0
Range [units] 1 .. 10 000 [A]
Default value 350 A Alternative config YES
Step 1 A
Comm object 8275 Related applications AMF, MRS
Config level Standard
Setpoint visibility
Conditioned by the setpoint Connection type (page 147).
Description
It is current limit for mains current protections and means maximal continuous mains current. Nominal
Current can be different from mains rated current value.
Note: To lock this setpoint against editing you also have to lock setpoint Nominal Current 1 (page 242),
Nominal Current 2 (page 246) and Nominal Current 3 (page 250).
Nominal Current
6 back to List of setpoints
