Omron R88D-GT series User Manual

3-12
3-1 Servo Drive Specifications
3
Specifications
 Control I/O Signals
CN1 Control Inputs
Pin
No.
Symbol Name Function/Interface
Control
mode
1+24VCW
24-V Open-collector Input
for Command Pulse
Input terminals for position command pulses.
These are selected by setting the Command Pulse Input
Selection (Pn40) to 0.
Line-Driver input:
Maximum response frequency: 500 kpps
Open-collector input:
Maximum response frequency: 200 kpps
Any of the following can be selected by using the Pn42 set-
ting: reverse and forward pulses (CW/CCW), feed pulse
and direction signal (PULS/SIGN), 90° phase difference
(phase A/B) signals (FA/FB).
Position
2
+24VCC
W
24-V Open-collector Input
for Command Pulse
3
+CW/
PULS/FA
Reverse Pulses Input/
Feed Pulses Input,
or 90° Phase Difference
Pulse Input (Phase A)
4
−CW/
PULS/FA
5
+CCW/
SIGN/FB
Forward Pulse Input/
Direction Signal,
or 90° Phase Difference
Pulse Input (Phase B)
6
−CCW/
SIGN/FB
7 +24VIN
12 to 24-VDC Power
Supply Input
Power supply input terminal (+12 to 24 VDC) for sequence
inputs.
All
8NOT
Reverse Drive Prohibit
Input
Reverse rotation overtravel input.
OFF: Prohibited, ON: Permitted
All
9POT
Forward Drive Prohibit
Input
Forward rotation overtravel input.
OFF: Prohibited, ON: Permitted
All
14
REF Speed Command Input Analog input terminal for speed commands.
*1
Speed
TREF1 Torque Command Input
Analog input terminal for torque command when Torque
Command/Speed Limit Selection (Pn5B) is set to 0.
*1
Torque
VLIM Speed Limit Input
Analog input terminal for speed limit when Torque Com-
mand/Speed Limit Selection (Pn5B) is set to 1.
*1
Torque
15 AGND Analog Input Ground Analog input ground. All
16
PCL Forward Torque Limit Input Analog input terminal for forward torque limit.
*1
Position,
speed
TREF2 Torque Command Input
Analog input terminal for torque command by setting the
Control Mode Selection (Pn02) and Torque Command/
Speed Limit Selection (Pn5B).
*1
Torque
17 AGND Analog Input Ground Analog input ground. All
18 NCL Reverse Torque Limit Input Analog input terminal for reverse torque limit.
*1
Position,
speed
20 SEN
Sensor ON Input
ON: Absolute encoder's multi-turn amount and initial incre-
mental pulses are sent.
Required signal when using an absolute encoder.
All
13 SENGND
