Omron R88D-GT series User Manual

13
Items to Check When Unpacking
 Understanding Decelerator Model Numbers (Backlash = 3' Max.)
R88G-HPG14A05100PBJ
Decelerator for
G-Series Servomotors
Applicable Servomotor Capacity
050
100
200
400
750
900
1K0
1K5
2K0
3K0
4K0
4K5
5K0
6K0
7K5
: 50 W
:100 W
:200 W
:400 W
:750 W
:900 W
:1 kW
:1.5 kW
:2 kW
:3 kW
:4 kW
:4.5 kW
:5 kW
:6 kW
:7.5 kW
Backlash = 3’ Max.
Gear Ratio
05
09
11
12
20
21
25
33
45
:1/5
:1/9 (only frame number 11A)
:1/11 (except frame number 65A)
:1/12 (only frame number 65A)
:1/20 (only frame number 65A)
:1/21 (except frame number 65A)
:1/25 (only frame number 65A)
:1/33
:1/45
Flange Size Number
11B
14A
20A
32A
50A
65A
:@40
:@60
:@90
:@120
:@170
:@230
Motor Type
Blank
P
S
T
:3,000-r/min cylindrical Servomotors
:flat Servomotors
:2,000-r/min Servomotors
:1,000-r/min Servomotors
Backlash
B :3’ max.
Option
Blank
J
:Straight shaft
:With key and tap
