3-132
3-8 Reactor Specifications
3
Specifications
3-8 Reactor Specifications
Connect a Reactor to the Servo Drive as a harmonic current control measure. Select a model
matching the Servo Drive to be used.
Specifications
Servo Drive Reactor
Model
Number of
power
phases
Model
Rated
current
Inductance Weight
R88D-GTA5L
Single-
phase
3G3AX-DL2002 1.6 A 21.4 mH Approx. 0.8 kg
R88D-GT01L
3G3AX-DL2004 3.2 A 10.7 mH Approx. 1.0 kg
R88D-GT02L
3G3AX-DL2007 6.1 A 6.75 mH Approx. 1.3 kg
R88D-GT04L
3G3AX-DL2015 9.3 A 3.51 mH Approx. 1.6 kg
R88D-GT01H
3G3AX-DL2002 1.6 A 21.4 mH Approx. 0.8 kg
R88D-GT02H
3G3AX-DL2004 3.2 A 10.7 mH Approx. 1.0 kg
R88D-GT04H
3G3AX-DL2007 6.1 A 6.75 mH Approx. 1.3 kg
R88D-GT08H
Single-
phase
3G3AX-DL2015 9.3 A 3.51 mH Approx. 1.6 kg
3-phase 3G3AX-AL2025 10.0 A 2.8 mH Approx. 2.8 kg
R88D-GT10H
Single-
phase
3G3AX-DL2015 9.3 A 3.51 mH Approx. 1.6 kg
3-phase 3G3AX-AL2025 10.0 A 2.8 mH Approx. 2.8 kg
R88D-GT15H
Single-
phase
3G3AX-DL2022 13.8 A 2.51 mH Approx. 2.1 kg
3-phase 3G3AX-AL2025 10.0 A 2.8 mH Approx. 2.8 kg
R88D-GT20H
3-phase
3G3AX-AL2055 20.0 A 0.88 mH Approx. 4.0 kg
R88D-GT30H
R88D-GT50H
3G3AX-AL2110 37.0 A 0.35 mH Approx. 5.0 kg
R88D-GT75H
3G3AX-AL2220 70.0 A 0.18 mH Approx. 10.0 kg
