3-116
3-5 Servo Relay Units and Cable Specifications
3
Specifications
Position Control Unit-Servo Relay Unit Cable Specifications
Position Control Unit Cable (XW2Z-@J-A3)
This Cable connects a Programmable Controller (CQM1-CPU43-V1) to a Servo Relay Unit (XW2B-
20J6-3B).
Cable Models
Connection Configuration and Dimensions
Wiring
Model Length (L) Outer diameter of sheath Weight
XW2Z-050J-A3 50 cm
7.5 dia.
Approx. 0.1 kg
XW2Z-100J-A3 1 m Approx. 0.1 kg
L
25
639
32.2
t = 15
CQM1
CQM1-CPU43-V1
Servo Relay Unit
XW2B-20J6-3B
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
No.
15
12
13
14
3
1
4
5
6
Servo Relay Unit
Cable: AWG28 × 4P + AWG28 × 4C
CQM1
Hood cover
To Next Page
