5-6 Forward and Reverse Drive Prohibit
5
Operating Functions
5-6 Forward and Reverse Drive Prohibit
Function
• When the Forward Drive Prohibit Input (POT: CN1 pin 9) and Reverse Drive Prohibit Input (NOT:
CN1 pin 8) are turned OFF, the Servomotor will stop rotating.
• You can stop the Servomotor from rotating beyond the device's operating range by connecting
limit inputs.
Parameters Requiring Settings
Operation
Stopping Methods When Forward/Reverse Drive Prohibit Is OFF
While the Forward Drive Prohibit Input (POT) is OFF, the Servomotor cannot be driven in the
forward direction, but it can be driven in the reverse direction. Conversely, while the Reverse Drive
Prohibit Input (NOT) is OFF, the Servomotor cannot be driven in the reverse direction, but it can be
driven in the forward direction.
With a vertical axis, there is a risk that the load may drop when drive is prohibited by the drive
prohibit input. To prevent this, it is recommended that the deceleration method be set to use
emergency stop torque in the Drive Prohibit Input Stop Selection parameter (Pn066), and that
stopping in the servo-lock state be set (set value: 2).
Parameter
No.
Parameter name Explanation Reference page
Pn04
Drive Prohibit Input
Selection
Enable or disable the Forward/Reverse Drive Prohibit In-
puts.
5-54
Pn66
Stop Selection for
Drive Prohibition
Input
Set the operation for decelerating to a stop after the For-
ward/Reverse Drive Prohibit Input turns OFF. Set whether
to use the dynamic brake to stop or free-running.
5-88
0
2
1
Stopped Status
Servo locked
Deceleration Method
Dynamic brake
Free run
Emergency Stop
To r que (Pn6E)
Stop Selection for Drive
Prohibition Input (Pn66)
POT (NOT) turns OFF.
Disables torque in drive
prohibited direction
