Omron R88D-GT series User Manual

4-42
4-3 Wiring Conforming to EMC Directives
4
System Design
 Selecting Other Parts for Noise Resistance
This section explains the criteria for selecting other connection components required to improve
noise resistance.
Understand each component's characteristics, such as its capacity, performance, and applicable
conditions when selecting the components.
For more details, contact the manufacturers directly.
Noise Filters for the Power Supply Input
• Use a noise filter to attenuate external noise and reduce noise emitted from the Servo Drive.
• Select a noise filter with a rated current that is at least two times greater than the effective load
current (the rated current of the main circuit power supply input given in Main Circuit and
Servomotor Connections on page 4-21).
Note 1. To attenuate noise at low frequencies below 200 kHz, use an isolation transformer and a
noise filter.
Note 2. To attenuate noise at high frequencies over 30 MHz, use a ferrite core and a high-frequency
noise filter with a feed-through capacitor.
Note 3. If multiple Servo Drives are connected to a single noise filter, select a noise filter with a rated
current at least two times the total rated current of all the Servo Drives.
Manufacturer Model
Rated
current
Applicable standards Remarks
NEC TOKIN
GT-2050 5 A
UL, CSA, VDE, TÜV
Single-
phase
GT-2100 10 A
GT-2150 15 A
GT-2150 20 A
HFP-2153 15 A
UL, CSA, TÜV
Three-
phase
HFP-2303 30 A
Okaya Electric
Industries Co.,
ltd.
SUP-EK10-ER-6 10 A
UL, cUL, TÜV
Single-
phase
SUP-EK15-ER-6 15 A
SUP-EK20-ER-6 20 A
SUP-EK30-ER-6 30 A
SUP-HL10-ER-6 10 A
UL, TÜV
Three-
phase
SUP-H15-ER-6 15 A
3SUP-HL30-ER-6 30 A
3SUP-HL75-ER-6 75 A
3SUP-HL100-ER-6 100 A
TDK
ZRCS2006-00S 6 A
UL, CSA, NEMKO
Single-
phase
ZRCS2010-00S 10 A
ZRCS2020-00S 20 A
ZRCS2030-00S 30 A
ZRCT5050-MF 50 A
UL, CSA, NEMKO
Three-
phase
ZRCT5080-MF 80 A
ZRCT5100-MF 100 A
