1-11
1-5 Applicable Standards
1
Features and System Configuration
The Servo Drives and Servomotors comply with UL 508C (file No. E179149) as long as the following
installation conditions 1 and 2 are met.
(1) Use the Servo Drive in a pollution degree 1 or 2 environment as defined in IEC 60664-1
(example: installation in an IP54 control panel).
(2) Be sure to connect a circuit breaker or fuse, which is a UL-listed product with LISTED and
mark, between the power supply and noise filter.
Refer to the following table for the rated current of the circuit breaker or fuse.
Use copper wiring with a temperature rating of 60°C or higher.
Korean Radio Regulations (KC)
The G-series Servo Drives comply with the Korean Radio Regulations (KC).
The G-series Servomotors do not comply with the Korean Radio Regulations (KC).
SEMI F47
Some Servo Drives conform to the SEMI F47 standard for momentary power interruptions (voltage
sag immunity) for no-load or light-load operation.
This standard applies to semiconductor manufacturing equipment.
Note 1. It does not apply to Servo Drivers with single-phase 100-V specifications or with
24-VDC specifications for the control power input.
Note 2. Always perform evaluation testing for SEMI F47 compliance in the actual system.
Drive model Circuit breaker (rated current) (A)
R88D-GTA5L 10
R88D-GT01L 10
R88D-GT02L 10
R88D-GT04L 10
R88D-GT01H 10
R88D-GT02H 10
R88D-GT04H 10
R88D-GT08H 15
R88D-GT10H 15
R88D-GT15H 20
R88D-GT20H 30
R88D-GT30H 50
R88D-GT50H 50
R88D-GT75H 60
To Next Page
