2-10

2-1 Standard Models

Standard Models and Dimensions

Decelerators for 1,000-r/min Servomotors

Note 1. The standard models have a straight shaft.

Note 2. Models with a key and tap are indicated with “J” at the end of the model number

(the suffix shown in the box). (Example: R88G-HPG32A05900TBJ)

Specifications

Model

Motor

capacity

Gear ratio

900 W

1/5 R88G-HPG32A05900TB

1/11 R88G-HPG32A11900TB@

1/21 R88G-HPG50A21900TB@

1/33 R88G-HPG50A33900TB@

2 kW

1/5 R88G-HPG32A052K0TB

1/11 R88G-HPG50A112K0TB@

1/21 R88G-HPG50A212K0TB@

1/25 R88G-HPG65A255K0SB@

3 kW

1/5 R88G-HPG50A055K0SB

1/11 R88G-HPG50A115K0SB@

1/20 R88G-HPG65A205K0SB@

1/25 R88G-HPG65A255K0SB@

4.5 kW

1/5 R88G-HPG50A054K5TB

1/12 R88G-HPG65A127K5SB@

1/20 R88G-HPG65A204K5TB@

6 kW

1/5 R88G-HPG65A057K5SB

1/12 R88G-HPG65A127K5SB@
